Professional Grade Steel Structure Agricultural Barns

A Wise Choice Beyond Traditional Wooden Structures
We are not merely building a warehouse; we are providing you with a long-term, reliable, and low-maintenance asset. Say goodbye to the decay, pest infestations, and high maintenance costs associated with wooden barns.

Diversified design to meet all your needs

We offer a variety of validated design solutions to meet different site, budget, and functional requirements.

According to appearance and drainage design:

Single slope barn: economical and practical, with simple drainage, suitable for small farms or attached storage.

Double slope (gable style) barn: Classic design, high utilization of internal space, atmospheric appearance, suitable for most farms.

Arched (semi-circular) barn: With a low wind resistance coefficient, it has strong resistance to wind and snow, modern design, and quick installation.

Multi span barn: designed for large commercial farms or cooperatives, providing column free large space for convenient operation of large machinery.

Classified by Function and Configuration:

Standard economy type: meets basic storage needs and offers the best cost-effectiveness.

Professional agricultural type: (recommended) comes standard with ventilation and moisture-proof systems, making it an ideal choice for storing grain and feed.

High end customized type: integrated insulation, solar roof, intelligent monitoring, etc., achieving environmental control and energy self-sufficiency.

A functional system optimized for agricultural storage

Intelligent ventilation system:

Roof mounted turbine fan (standard): continuously extracts hot and humid air using natural wind power.

Side wall electric louvers (optional): achieve forced ventilation, can achieve up to 5 full chamber air replacements per hour, effectively preventing mold growth.

Comprehensive moisture-proof solution:

Aluminum foil insulation pad: blocks the generation of condensed water and keeps the warehouse dry.

Self draining roof: With a standard slope of 12° and a 300mm wide integrated sink, rainwater can be quickly diverted.

Protection system:

Bird proof design: 30mm eave edge+reserved bird repellent installation slot to prevent bird damage and pollution.

Wear resistant flooring: optional 2mm thick diamond steel plate, resistant to frequent crushing by agricultural machinery.

Technical specifications and high standard manufacturing

Main structure:

Main steel: ASTM A572 Gr.50 high-strength steel.

Maximum net span: 36 meters (reducing 43% of columns, making the space more spacious).

Enclosure system:

Roof panel/wall panel: double-sided 275g/㎡ hot-dip galvanized steel plate, with a galvanized layer exceeding 2.1 times the ISO standard.

Optional electrostatic powder coating, RAL standard color code, salt spray resistance for 2000 hours.

Load capacity:

Wind resistance: 0.55 kN/㎡ (equivalent to resisting wind speeds of 44.6m/s).

Ground load: standard 3 tons/square meter, can be reinforced up to 8 tons/square meter.

Six lifting points are pre-set on the roof, with a single static load of 5 tons.

Precision prefabrication:

The length tolerance of the component is ≤± 1.5mm/6m.

Laser pre drilling, cumulative installation error<2mm.

Use 3M™ AC-257 sealing tape for seams ensures lifelong waterproofing.

Modular design accompanies your business growth

Basic module: 12m (width) x 30m (length) x 6m (eave height).

Easy Expansion: In the future, you can easily expand your length or width in units of 8 meters without rebuilding, protecting your initial investment.
